Electric Coolant Pump EPL60L-03
Classification:
Technical data
| Rated flow head | 16L/min@7m |
| Power | 60W |
| Voltage range | 8 ~ 16VDC |
| Maximum flow | 30L/min |
| Maximum lift | 8m |
| Noise | ≤40dB@0.5m |
| Communication mode | PWM,LIN |
Product Details
- Description
- Product Advantages
- Technical Data
-
- Commodity name: Electric Coolant Pump EPL60L-03
- Commodity ID: EPL60L-03
<table style="border-collapse:collapse; width:auto"> <colgroup> <col style="width:207.00pt" width="276" /> <col style="width:163.50pt" width="218" /> </colgroup> <tbody> <tr> <td x:str=""><strong>Rated flow head</strong></td> <td x:str="">16L/min@7m</td> </tr> <tr> <td x:str=""><strong>Power</strong></td> <td x:str="">60W</td> </tr> <tr> <td x:str=""><strong>Voltage range</strong></td> <td x:str="">8 ~ 16VDC</td> </tr> <tr> <td x:str=""><strong>Maximum flow</strong></td> <td x:str="">30L/min</td> </tr> <tr> <td x:str=""><strong>Maximum lift</strong></td> <td x:str="">8m</td> </tr> <tr> <td x:str=""><strong>Noise</strong></td> <td x:str="">≤40dB@0.5m</td> </tr> <tr> <td x:str=""><strong>Communication mode</strong></td> <td x:str="">PWM,LIN</td> </tr> </tbody> </table>
Model EPL60L-03 Rated Flow and Head 16L/min@7m Rated Power 60W Voltage Range 8～16V DC Max. head 30L/min Max. flow 8m Noise ≤40dB(A) @ 0.5m Communication PWM,LIN Range of Application
1) Ambient Temperature: -40～110℃;
2) Medium: Antifreeze(50:50/ Ethylene Glycol: Water);
3) Medium Temperature：-40～110 ℃.
Function Description
1) When there is no input signal, pump will runs at the rate constant speed by default in rated flow point;
2) Fault diagnosis: idling, stall, over-current / phase line anomaly, over-temperature, signal error, overvoltage, under-voltage, and so on;
3) PWM control function;
4)PWM feedback function.
-
Electric Water Pump applied to automotive thermal management systems
1.Compact structure
2.easy installation
3.flexible control
4.Reliable performance
5.low noise
6.high efficiency
7.long lifespan
-
key word:
Electric Water Pump for Engine Cooling
electric water pump in car
car electric water pump manufacturer
| Model | EPL60L-03 |
| Rated Flow and Head | 16L/min@7m |
| Rated Power | 60W |
| Voltage Range | 8～16V DC |
| Max. head | 30L/min |
| Max. flow | 8m |
| Noise | ≤40dB(A) @ 0.5m |
| Communication | PWM,LIN |
Range of Application
1) Ambient Temperature: -40～110℃;
2) Medium: Antifreeze(50:50/ Ethylene Glycol: Water);
3) Medium Temperature：-40～110 ℃.
Function Description
1) When there is no input signal, pump will runs at the rate constant speed by default in rated flow point;
2) Fault diagnosis: idling, stall, over-current / phase line anomaly, over-temperature, signal error, overvoltage, under-voltage, and so on;
3) PWM control function;
4)PWM feedback function.
