Liquid Cooling Pump EPH2500H-21
Classification:
Technical data
| Model | EPH2500H-21 |
| Rated Flow and Head | 400L/min@20m |
| Rated Power | ≤2900W |
| Voltage Range | 9～32V DC |
| Insulation Level | IP67 |
| Life Span | ≥12000h |
| Speed | 6750rpm |
| Highest Efficiency | 54% |
| Noise Index | ≤75dB(A) |
Product Details
- Description
- Product Advantages
- Technical Data
-
- Commodity name: Liquid Cooling Pump EPH2500H-21
- Commodity ID: EPH2500H-21
<br><table align="center" border="1" cellpadding="0" cellspacing="0" style="width:100%;"> <tbody> <tr> <td><strong>Model</strong></td> <td>EPH2500H-21</td> </tr> <tr> <td><strong>Rated Flow and Head</strong></td> <td>400L/min@20m</td> </tr> <tr> <td><strong>Rated Power</strong> </td> <td>≤2900W</td> </tr> <tr> <td><strong>Voltage Range</strong></td> <td>9～32V DC</td> </tr> <tr> <td><strong>Insulation Level</strong></td> <td>IP67</td> </tr> <tr> <td><strong>Life Span</strong></td> <td>≥12000h</td> </tr> <tr> <td><strong>Speed</strong></td> <td>6750rpm</td> </tr> <tr> <td><strong>Highest Efficiency</strong></td> <td>54%</td> </tr> <tr> <td><strong>Noise Index</strong></td> <td>≤75dB(A)</td> </tr> </tbody> </table>
Model EPH2500H-21 Rated Flow and Head 400L/min@20m Rated Power ≤2900W Voltage Range 9～32V DC Insulation Level IP67 Life Span ≥12000h Speed 6750rpm Highest Efficiency 54% Noise Index ≤75dB(A) Application Field
Ambient Temperature: -40 to 85°C;
Power components of hydrogen fuel cell stack thermal management system or other thermal management system;
System pressure: ≤250kPa；
Medium: antifreeze（50:50/Ethylene glycol: Water);
Medium Temperature: -40～90 ℃;
Product application environment: Sputtering of acidic liquids and crushing stones are not allowed;
Power Supply: DC power;
Magnetic impurities are not allowed in the medium, and the particle size is required to be ≤350um.
Communication
Can Bus Control: adjustable speed;
Fault Diagnosis: idling, over-voltage, under-voltage, over-current, locked-rotor, over-temperature, low-voltage power supply reverse connection protection and CAN communication loss protection
-
Electric Water Pump applied to Hydrogen fuel engine system/energy storage battery thermal management liquid cooling system.
1.Shielding structure, low noise, high stability, long life;
2.Dielectric insulation;
3.High voltage water pump control;
4.Permanent magnet synchronous motor, high efficiency.
-
key word:
cooling pump
coolant pump
automotive electric coolant pump
auto electric water pump
marine pumps
battery cooling pump
| Model | EPH2500H-21 |
| Rated Flow and Head | 400L/min@20m |
| Rated Power | ≤2900W |
| Voltage Range | 9～32V DC |
| Insulation Level | IP67 |
| Life Span | ≥12000h |
| Speed | 6750rpm |
| Highest Efficiency | 54% |
| Noise Index | ≤75dB(A) |
Application Field
Ambient Temperature: -40 to 85°C;
Power components of hydrogen fuel cell stack thermal management system or other thermal management system;
System pressure: ≤250kPa；
Medium: antifreeze（50:50/Ethylene glycol: Water);
Medium Temperature: -40～90 ℃;
Product application environment: Sputtering of acidic liquids and crushing stones are not allowed;
Power Supply: DC power;
Magnetic impurities are not allowed in the medium, and the particle size is required to be ≤350um.
Communication
Can Bus Control: adjustable speed;
Fault Diagnosis: idling, over-voltage, under-voltage, over-current, locked-rotor, over-temperature, low-voltage power supply reverse connection protection and CAN communication loss protection
