Liquid Cooling Pump EPH900H-03
Classification:
Technical data
| Model | EPH900H-03 |
| Rated Flow and Head | 210L/min@13.5m |
| Rated Power | 900W |
| Voltage Range | 9～32V DC |
| Insulation Level | IP67 |
| Life Span | ≥15000h |
| Speed | 4500rpm |
| Highest Efficiency | 60% |
| Noise Index | ≤65dB(A) |
Product Details
- Description
- Product Advantages
- Technical Data
-
- Commodity name: Liquid Cooling Pump EPH900H-03
- Commodity ID: EPH900H-03
<br><table align="center" border="1" cellpadding="0" cellspacing="0" style="width:100%;"> <tbody> <tr> <td><strong>Model</strong></td> <td>EPH900H-03</td> </tr> <tr> <td><strong>Rated Flow and Head</strong></td> <td>210L/min@13.5m</td> </tr> <tr> <td><strong>Rated Power</strong></td> <td>900W</td> </tr> <tr> <td><strong>Voltage Range</strong></td> <td>9～32V DC</td> </tr> <tr> <td><strong>Insulation Level</strong></td> <td>IP67</td> </tr> <tr> <td><strong>Life Span</strong></td> <td>≥15000h</td> </tr> <tr> <td><strong>Speed</strong></td> <td>4500rpm</td> </tr> <tr> <td><strong>Highest Efficiency</strong></td> <td>60%</td> </tr> <tr> <td><strong>Noise Index</strong></td> <td>≤65dB(A)</td> </tr> </tbody> </table>
Model EPH900H-03 Rated Flow and Head 210L/min@13.5m Rated Power 900W Voltage Range 9～32V DC Insulation Level IP67 Life Span ≥15000h Speed 4500rpm Highest Efficiency 60% Noise Index ≤65dB(A) Application Field
Ambient Temperature: -40 to 85°C;
System pressure: ≤250kPa；
Medium: antifreeze（50:50/Ethylene glycol: Water);
Medium Temperature: -40～90 ℃;
Product application environment: Sputtering of acidic liquids and crushing stones are not allowed;
Power Supply: DC power;
Magnetic impurities are not allowed in the medium, and the particle size is required to be ≤350um.
Communication
Can Bus Control: adjustable speed;
Fault Diagnosis: idling, over-voltage, under-voltage, over-current, locked-rotor,
over-temperature, low-voltage power supply reverse connection protection and CAN
communication loss protection
-
Electric Water Pump applied to Hydrogen fuel engine system/energy storage battery thermal management liquid cooling system.
1.Shielding structure, low noise, high stability, long life;
2.Dielectric insulation;
3.High voltage water pump control;
4.Permanent magnet synchronous motor, high efficiency.
-
key word:
cooling pump
coolant pump
coolant transfer pump
automotive electric coolant pump
coolant recirculation pump
auto engine water pump
| Model | EPH900H-03 |
| Rated Flow and Head | 210L/min@13.5m |
| Rated Power | 900W |
| Voltage Range | 9～32V DC |
| Insulation Level | IP67 |
| Life Span | ≥15000h |
| Speed | 4500rpm |
| Highest Efficiency | 60% |
| Noise Index | ≤65dB(A) |
Application Field
Ambient Temperature: -40 to 85°C;
System pressure: ≤250kPa；
Medium: antifreeze（50:50/Ethylene glycol: Water);
Medium Temperature: -40～90 ℃;
Product application environment: Sputtering of acidic liquids and crushing stones are not allowed;
Power Supply: DC power;
Magnetic impurities are not allowed in the medium, and the particle size is required to be ≤350um.
Communication
Can Bus Control: adjustable speed;
Fault Diagnosis: idling, over-voltage, under-voltage, over-current, locked-rotor,
over-temperature, low-voltage power supply reverse connection protection and CAN
communication loss protection
