Electric Water Pump EPL350M-03
Classification:
Technical data
| Rated flow head | 70L/min@13m |
| Power | 380W |
| Voltage range | 16 ~ 32VDC |
| Maximum flow | 88L/min |
| Maximum lift | 22m |
| Noise | ≤61dB@0.5m |
| Communication mode | PWM |
Product Details
- Description
- Product Advantages
- Technical Data
-
- Commodity name: Electric Water Pump EPL350M-03
- Commodity ID: EPL350M-03
<table height="122" style="border-collapse:collapse; width:auto"> <colgroup> <col style="width:207.00pt" width="276" /> <col style="width:163.50pt" width="218" /> </colgroup> <tbody> <tr> <td x:str=""><strong>Rated flow head</strong></td> <td x:str="">70L/min@13m</td> </tr> <tr> <td x:str=""><strong>Power</strong></td> <td x:str="">380W</td> </tr> <tr> <td x:str=""><strong>Voltage range</strong></td> <td x:str="">16 ~ 32VDC</td> </tr> <tr> <td x:str=""><strong>Maximum flow</strong></td> <td x:str="">88L/min</td> </tr> <tr> <td x:str=""><strong>Maximum lift</strong></td> <td x:str="">22m</td> </tr> <tr> <td x:str=""><strong>Noise</strong></td> <td x:str="">≤61dB@0.5m</td> </tr> <tr> <td x:str=""><strong>Communication mode</strong></td> <td x:str="">PWM</td> </tr> </tbody> </table>
Model
EPL350M-03
Rated Flow and Head
48L/min @ 18m
Rated Power
360W
Voltage Range
16～32V DC
Insulation Level
Class H
Life Span
≥20000h
Speed
1000rpm～6050rpm
IP Class
IP67
Noise Index
≤61dB(A)
Application Field
Ambient Temperature: -40 to 110°C;
On-board water circulation cooling system;
Medium: Antifreeze(50:50/ Ethylene Glycol: Water);
Medium Temperature: -40 to 100°C;
Relative air humidity: ≤100%RH;
Functional Description
When there is no input signal, pump will not work;
PWM control function;
PWM feedback function;
Fault diagnosis: idling, stall, over-current / phase line anomaly, over-temperature, overvoltage, under-voltage, and so on.
-
Electric Water Pump applied to automotive thermal management systems
1.Compact structure
2.easy installation
3.flexible control
4.Reliable performance
5.low noise
6.high efficiency
7.long lifespan
-
key word:
cooling pump
coolant pump
12v coolant circulation pump
automotive water pump
electric vehicle water pump
automotive electric coolant pump
12v electric coolant pump
EV electric water pump
electric water pump for
|
Model |
EPL350M-03 |
|
Rated Flow and Head |
48L/min @ 18m |
|
Rated Power |
360W |
|
Voltage Range |
16～32V DC |
|
Insulation Level |
Class H |
|
Life Span |
≥20000h |
|
Speed |
1000rpm～6050rpm |
|
IP Class |
IP67 |
|
Noise Index |
≤61dB(A) |
Application Field
Ambient Temperature: -40 to 110°C;
On-board water circulation cooling system;
Medium: Antifreeze(50:50/ Ethylene Glycol: Water);
Medium Temperature: -40 to 100°C;
Relative air humidity: ≤100%RH;
Functional Description
When there is no input signal, pump will not work;
PWM control function;
PWM feedback function;
Fault diagnosis: idling, stall, over-current / phase line anomaly, over-temperature, overvoltage, under-voltage, and so on.
