<table height="122" style="border-collapse:collapse; width:auto"> <colgroup> <col style="width:207.00pt" width="276" /> <col style="width:163.50pt" width="218" /> </colgroup> <tbody> <tr> <td x:str=""><strong>Rated flow head</strong></td> <td x:str="">70L/min@13m</td> </tr> <tr> <td x:str=""><strong>Power</strong></td> <td x:str="">380W</td> </tr> <tr> <td x:str=""><strong>Voltage range</strong></td> <td x:str="">16 ~ 32VDC</td> </tr> <tr> <td x:str=""><strong>Maximum flow</strong></td> <td x:str="">88L/min</td> </tr> <tr> <td x:str=""><strong>Maximum lift</strong></td> <td x:str="">22m</td> </tr> <tr> <td x:str=""><strong>Noise</strong></td> <td x:str="">&le;61dB@0.5m</td> </tr> <tr> <td x:str=""><strong>Communication mode</strong></td> <td x:str="">PWM</td> </tr> </tbody> </table>

Application Field

Ambient Temperature: -40 to 110°C;

On-board water circulation cooling system;

Medium: Antifreeze(50:50/ Ethylene Glycol: Water);

Medium Temperature: -40 to 100°C;

Relative air humidity: ≤100%RH;

Functional Description

When there is no input signal, pump will runs at the rate constant speed by default in

rated flow point;

PWM control function;

PWM feedback function;

Fault diagnosis: idling, stall, over-current / phase line anomaly, over-temperature,

overvoltage, under-voltage, and so on.
