Liquid Cooling Pump EPH900H-35
Classification:
Technical data
| Model | EPH900H-00 |
| Rated Flow and Head | 165L/min@15.2m |
| Rated Power | 900W |
| Rated Voltage | 545V DC |
| Max. head | 210L/min |
| Max. flow | 18.9m |
| Noise | ≤60dB(A) @ 1m |
| Communication | CAN2.0B |
Product Details
- Description
- Product Advantages
- Technical Data
-
- Commodity name: Liquid Cooling Pump EPH900H-35
- Commodity ID: EPH900H-35
<br><table align="center" border="1" cellpadding="0" cellspacing="0" style="width:100%;"> <tbody> <tr> <td><strong>Model</strong></td> <td>EPH900H-00</td> </tr> <tr> <td><strong>Rated Flow and Head</strong></td> <td>165L/min@15.2m</td> </tr> <tr> <td><strong>Rated Power</strong> </td> <td>900W</td> </tr> <tr> <td><strong>Rated Voltage </strong></td> <td>545V DC</td> </tr> <tr> <td><strong>Max. head</strong></td> <td>210L/min</td> </tr> <tr> <td><strong>Max. flow</strong></td> <td>18.9m</td> </tr> <tr> <td><strong>Noise</strong></td> <td>≤60dB(A) @ 1m </td> </tr> <tr> <td><strong>Communication</strong></td> <td>CAN2.0B</td> </tr> </tbody> </table>
Model
EPH900H-35
Rated Flow and Head
165L/min@12.5m
Rated Power
≤900W
Voltage Range
9～32V DC
Insulation Level
IP67
Life Span
≥15000h
Speed
4750rpm
Highest Efficiency
60%
Noise Index
≤60dB(A)
Application Field
Ambient Temperature: -40 to 85°C;
System pressure: ≤250kPa；
Medium: antifreeze（50:50/Ethylene glycol: Water);
Medium Temperature: -40～90 ℃;
Product application environment: Sputtering of acidic liquids and crushing stones are not allowed;
Power Supply: DC power;
Magnetic impurities are not allowed in the medium, and the particle size is required to be ≤350um.
Communication
Can Bus Control: adjustable speed;
Fault Diagnosis: idling, over-voltage, under-voltage, over-current, locked-rotor, over-temperature, low-voltage power supply reverse connection protection and CAN communication loss protection
-
Electric Water Pump applied to Hydrogen fuel engine system/energy storage battery thermal management liquid cooling system.
1.Shielding structure, low noise, high stability, long life;
2.Dielectric insulation;
3.High voltage water pump control;
4.Permanent magnet synchronous motor, high efficiency.
-
key word:
cooling pump
coolant pump
coolant transfer pump
automotive electric coolant pump
coolant recirculation pump
auto engine water pump
|
Model |
EPH900H-35 |
|
Rated Flow and Head |
165L/min@12.5m |
|
Rated Power |
≤900W |
|
Voltage Range |
9～32V DC |
|
Insulation Level |
IP67 |
|
Life Span |
≥15000h |
|
Speed |
4750rpm |
|
Highest Efficiency |
60% |
|
Noise Index |
≤60dB(A) |
Application Field
Ambient Temperature: -40 to 85°C;
System pressure: ≤250kPa；
Medium: antifreeze（50:50/Ethylene glycol: Water);
Medium Temperature: -40～90 ℃;
Product application environment: Sputtering of acidic liquids and crushing stones are not allowed;
Power Supply: DC power;
Magnetic impurities are not allowed in the medium, and the particle size is required to be ≤350um.
Communication
Can Bus Control: adjustable speed;
Fault Diagnosis: idling, over-voltage, under-voltage, over-current, locked-rotor, over-temperature, low-voltage power supply reverse connection protection and CAN communication loss protection
