Electric Coolant Pump EPL120L-01
Classification:
Technical data
| Rated Flow and Head | 25L/min@12m |
| Rated Power | 130W |
| Voltage Range | 8～16V DC |
| Max. Flow | 50L/min |
| Max. Head | 13m |
| Speed | 1200rpm～6000rpm |
| IP Class | IP67/IP6K9K |
Product Details
- Description
- Product Advantages
- Technical Data
-
- Commodity name: Electric Coolant Pump EPL120L-01
- Commodity ID: EPL120L-01
<table style="border-collapse:collapse; width:auto"> <colgroup> <col style="width:207.00pt" width="276" /> <col style="width:163.50pt" width="218" /> </colgroup> <tbody> <tr> <td>Rated Flow and Head</td> <td>25L/min@12m</td> </tr> <tr> <td>Rated Power </td> <td>130W</td> </tr> <tr> <td>Voltage Range</td> <td>8～16V DC</td> </tr> <tr> <td>Max. Flow</td> <td>50L/min</td> </tr> <tr> <td>Max. Head</td> <td>13m</td> </tr> <tr> <td>Speed</td> <td>1200rpm～6000rpm</td> </tr> <tr> <td>IP Class</td> <td>IP67/IP6K9K</td> </tr> </tbody> </table>
Model EPL120L-01 Rated Flow and Head 25L/min@12m Rated Power 130W Voltage Range 8～16V DC Max. Flow 50L/min Max. Head 13m Speed 1200rpm～6000rpm IP Class IP67/IP6K9K Application Field
Ambient Temperature: -40 to 110°C;
Conveyed Medium: Coolant (a mixture of water and ethylene glycol);
Medium Temperature: -40 to 100°C;Functional Description
Constant speed operation;
Protection functions: Dry-running, Overvoltage, Undervoltage, Overcurrent, Locked-rotor, Overtemperature, Reverse polarity protection of the low-voltage power supply;
PWM control function;
PWM feedback function;
-
Electric Water Pump applied to automotive thermal management systems
1.Compact structure
2.easy installation
3.flexible control
4.Reliable performance
5.low noise
6.high efficiency
7.long lifespan
-
key word:
cooling pump
coolant pump
automotive water pump
auto electric water pump
auto engine water pump
coolant pump for car
2006 bmw 525i electric water pump
| Model | EPL120L-01 |
| Rated Flow and Head | 25L/min@12m |
| Rated Power | 130W |
| Voltage Range | 8～16V DC |
| Max. Flow | 50L/min |
| Max. Head | 13m |
| Speed | 1200rpm～6000rpm |
| IP Class | IP67/IP6K9K |
Application Field
Ambient Temperature: -40 to 110°C;
Conveyed Medium: Coolant (a mixture of water and ethylene glycol);
Medium Temperature: -40 to 100°C;
Functional Description
Constant speed operation;
Protection functions: Dry-running, Overvoltage, Undervoltage, Overcurrent, Locked-rotor, Overtemperature, Reverse polarity protection of the low-voltage power supply;
PWM control function;
PWM feedback function;
